Gree GMV-140WL/A-T User Manual

DC Inverter Multi VRF System User Manual
22
db
On
09
On
OC
On
Refrigerant is normal and unit will display as in the
left for 2s. Then next step starts.
10_ Status
judgments of
outdoor valves
before startup
db
On
10
On
ON
On
Valves of ODU are being inspected. Compressor
will start operation for 2min or so and then stop.
The opening and closing status of outdoor valves
are as below:
db
On
10
On
U6
On
Outdoor valves are not fully turned on. Press main
board’s SW6 button and display shows “db 09
OC”. Then check if the gas and liquid valves of
ODU are completely open. After confirmation,
press the SW6 button again. Then compressor
will start running for about 2min to inspect the
status of valves.
db
On
10
On
OC
On
Valves status is normal. Unit will display as in the
left for 2s and then start next step.
12_ Confirm
debugging
startup
db
On
12
On
AP
Blink
Ready for units to start debugging. Press main
board’s SW7 button to confirm startup of
debugging. 2s later, main board will display as
below:
db
On
12
On
AE
On
Startup is confirmed. After displaying for 2s, system
will choose “15_Cooling debugging” or “16_Heating
debugging” according to ambient temperature. If
the project requests to add refrigerant but it is
not complemented before debugging, then
refrigerant can be added in this process
through the L-VALVE.
15_ Cooling
debugging
db
On
15
On
AC
On
Debugging for cooling mode. If no malfunction
occurs for 20min when compressor is running, then
system will start progress 17;
db
On
15
On
Error
code
On
Malfunction occurs when debugging for cooling
mode. After all malfunctions are eliminated,
system will start next step.
16_ Heating
debugging
db
On
16
On
AH
On
Debugging for heating mode. If no malfunction
occurs for 20min when compressor is running, then
system will start progress 17;
db
On
16
On
Error
code
On
Malfunction occurs when debugging for heating
mode. After all malfunctions are eliminated,
system will start next step.
17_
Debugging
finished
01
On
OFF
On
OFF
On
The entire unit has finished debugging and under
standby-by condition.
5.2.3 Appendix: Reference of normal operation parameters
No.
Debug item
Parameter name
Unit
Reference
1
System
parameters
ODU
parameters
Outdoor
temperature
℃
——
2
Compressor
discharge temp
℃
●When compressor starts, discharge temp in
cool mode is within 70~105℃ and at least 10℃
higher than the high pressure saturation temp;
●As for temp in heat mode, it is within 65~90℃
and at least 10℃ higher than the high pressure
saturation temp.
3
Defrosting temp
℃
●In cool mode, defrosting temp is 4~10℃ lower
than system’s high pressure value;
●In heat mode, defrosting temp is about 2℃
different from system’s low pressure value.
4
System high
pressure
℃
●In cool mode, the normal high pressure value
is within 20℃~55℃. According to the change of
ambient temp and system’s operating capacity,
the high pressure value will be 10℃ ~30℃
higher than ambient temp. The higher ambient
