Gree GMV-280WM/G-X Service Manual

Gree GMV6 DC Inverter VRF Units Service Manual
278
No.
Name
Material code
Vulnerable part *
Qty
23
Left side plate assembly
017037060016P
1
24
Chassis assembly
017000000334P
1
25
Oil separator
035028060002
*
1
26
Filter
07415200002
*
2
27
Solenoid valve
43000072
*
1
28
Electronic expansion valve
072009060013
*
1
29
Electronic expansion valve coil
072002000011
*
1
30
Filter
07222025
*
1
31
Solenoid valve
072008000005
*
2
32
Gas-liquid separator
035027060002
*
1
33
Cut-off valve
07334100013
*
1
34
Cut-off valve
07334100014
*
1
35
Covering plate (front)
012035000237P
1
36
Panel (upper)
012073000244P
1
37
Panel (bottom)
012073000245P
1
38
Temperature sensor assembly (lower)
390002060033
*
1
39
Solenoid valve coil 220-240V/50/60Hz-1400
072001060008
*
1
40
Solenoid valve coil 220-240V/50/60Hz-1400
072001060007
*
1
41
4-way valve coil
072010060002
*
1
42
Solenoid valve coil
072001060006
*
1
43
Solenoid valve coil
072001060009
*
1
44
Electric heating belt (compressor)
7651521244
*
1
45
Pressure sensor
32218000009
*
1
46
Pressure sensor
32218000008
*
1
47
Electronic expansion valve
43044100190
*
1
48
Two-way filter
07220016
*
1
49
Muter (copper and steel)
07245008
*
1
50
EXV coil UKV
4304413250
*
1
51
Compressor and its accessories
009001000190
*
1
52
Pressure switch
4602000911
*
1
53
Right side plate assembly
017038060017P
1
54
Electric appliance box assembly
100002060451
*
1
55
Communication interface board
300014060038
*
1
56
Terminal board (5 bits)
422000060055
*
1
57
Terminal board (4 bits)
422000060004
*
1
58
Main board
300027000591
*
1
59
Filter board
300020060006
*
1
60
Main board
300027060076
*
1
61
Main board
300027000583
*
1
62
Reactor
450004060009
*
1
63
Radiator
4901800008801
*
1
Above data is subject to change without notice,pls reference the SP in global service website.
