Gree GMV-335WM/G-X Service Manual

Gree GMV6 DC Inverter VRF Units Service Manual
283
Appendixes
Appendix 1 Temperature Senor Resistance and Temperature
Relationship Table
Environmental temperature sensor 15kΩ resistance ~ voltage correspondence table (including
outdoor and indoor environment temperature sensors)
Temperature
(°C)
Resistance
(kΩ)
Voltage (V)
Temperature
(°C)
Resistance
(kΩ)
Voltage (V)
-20
144 0.311
71
2.523 2.825
-19
138.1 0.323
72
2.439 2.838
-18
128.6 0.345
73
2.358 2.852
-17
121.6 0.362
74
2.28 2.865
-16
115 0.381
75
2.205 2.877
-15
108.7 0.4
76
2.133 2.889
-14
102.9 0.42
77
2.064 2.901
-13
97.4 0.44
78
1.997 2.912
-12
92.22 0.462
79
1.933 2.923
-11
87.35 0.484
80
1.871 2.934
-10
82.75 0.506
81
1.811 2.945
-9
78.43 0.53
82
1.754 2.955
-8
74.35 0.554
83
1.699 2.964
-7
70.5 0.579
84
1.645 2.974
-6
66.88 0.605
85
1.594 2.983
-5
63.46 0.631
86
1.544 2.992
-4
60.23 0.658
87
1.497 3.001
-3
57.18 0.686
88
1.451 3.009
-2
54.31 0.714
89
1.408 3.017
-1
51.59 0.743
90
1.363 3.025
0
49.02 0.773
91
1.322 3.033
1
46.8 0.801
92
1.282 3.04
2
44.31 0.835
93
1.244 3.047
3
42.14 0.866
94
1.207 3.054
4
40.09 0.899
95
1.171 3.061
5
38.15 0.931
96
1.136 3.068
6
36.32 0.965
97
1.103 3.074
7
34.58 0.998
98
1.071 3.08
8
32.94 1.033
99
1.039 3.086
9
31.38 1.067
100
1.009 3.092
10
29.9 1.102
101
0.98 3.098
11
28.51 1.138
102
0.952 3.103
12
27.18 1.174
103
0.925 3.108
13
25.92 1.21
104
0.898 3.114
14
24.73 1.246
105
0.873 3.119
15
23.6 1.282
106
0.848 3.123
16
22.53 1.319
107
0.825 3.128
17
21.51 1.356
108
0.802 3.133
