Pipeline temperature sensor 20kΩ resistance ~ voltage correspondence table (including defrosting
temperature sensor, subcooler temperature sensor, gas-liquid separator temperature sensor, IDU inlet
and outlet tube temperature sensor)
Temperature
(°C)
Resistance
(kΩ)
Voltage (V)
Temperature
(°C)
Resistance
(kΩ)
Voltage (V)
-30
361.8 0.173
66
3.998 2.75
-29
339.8 0.183
67
3.861 2.766
-28
319.2 0.195
68
3.729 2.781
-27
300 0.206
69
3.603 2.796
-26
282.2 0.218
70
3.481 2.811
-25
265.5 0.231
71
3.364 2.825
-24
249.9 0.245
72
3.252 2.838
-23
235.3 0.259
73
3.144 2.852
-22
221.6 0.273
74
3.04 2.865
-21
208.9 0.288
75
2.94 2.877
-20
196.9 0.304
76
2.844 2.889
-19
181.4 0.328
77
2.752 2.901
-18
171.4 0.345
78
2.663 2.912
-17
162.1 0.362
79
2.577 2.923
-16
153.3 0.381
80
2.495 2.934
-15
145 0.4
81
2.415 2.944
-14
137.2 0.42
82
2.339 2.954
-13
129.9 0.44
83
2.265 2.964
-12
123 0.462
84
2.194 2.974
-11
116.5 0.484
85
2.125 2.983
-10
110.3 0.507
86
2.059 2.992
-9
104.6 0.53
87
1.996 3.001
-8
99.13 0.554
88
1.934 3.009
-7
94 0.579
89
1.875 3.017
-6
89.17 0.605
90
1.818 3.025
-5
84.61 0.631
91
1.763 3.033
-4
80.31 0.658
92
1.71 3.04
-3
76.24 0.686
93
1.658 3.047
-2
72.41 0.714
94
1.609 3.054
-1
68.79 0.743
95
1.561 3.061
0
65.37 0.773
96
1.515 3.068
1
62.13 0.804
97
1.47 3.074
