Gree GMV6 DC Inverter VRF Units Service Manual
205
4.4 Electronic Expansion Valve
Specifications
Description
Two types of electronic expansion valves are adopted by the unit:
Heating electronic expansion valve with the largest openness of 3000 pls and 6-core coil.
Subcooling electronic expansion valve and EVI electronic expansion valve with the largest
openness of 480 pls and 5-core coil.
The electronic expansion valve is us
ed to control the flow. When the electronic
expansion valve is closed (the openness is 0 pls), the flow is stopped.
Circuit diagram
Layout of electrical appliance box
Physical position
Models: GMV-224WM/G-X, GMV-280WM/G-X, GMV-335WM/G-X
