Gree GMV6 DC Inverter VRF Units Service Manual
5
Model - GMV-735WM/G-X GMV-785WM/G-X GMV-839WM/G-X GMV-895WM/G-X
Gas pipe mm Φ31.8 Φ31.8 Φ31.8 Φ31.8
Liquid pipe mm Φ19.05 Φ19.05 Φ19.05 Φ19.05
Outline dimensions
(W × D × H)
mm
930×775×1690+
1340×775×1690
930×775×1690+
1340×775×1690
930×775×1690+
1340×775×1690
930×775×1690+
1340×775×1690
Packing dimensions
(W × D × H)
mm
1000×830×1855+
1400×830×1855
1000×830×1855+
1400×830×1855
1000×830×1855+
1400×830×1855
1000×830×1855+
1400×830×1855
Net weight kg 220+290 220+290 220+295 215+350
Gross weight kg 230+305 230+305 230+310 225+365
Model - GMV-950WM/G-X GMV-1015WM/G-X GMV-1064WM/G-X GMV-1119W M/G-X
HP HP 34 36 38 40
Combination mode
- 12+22 14+22 18+20 18+22
-
GMV-335WM/G-X+
GMV-615WM/G-X
GMV-400WM/G-X+
GMV-615WM/G-X
GMV-504WM/G-X+
GMV-560WM/G-X
GMV-504WM/G-X+
GMV-615WM/G-X
Cooling capacity kW 95.0 101.5 106.4 111.9
Heating capacity kW 106.5 114.0 119.5 125.5
Outdoor static
pressure
Pa 0/110 0/110 0/110 0/110
Noise (sound
pressure level)
dB(A) 65 65 65 65
Power -
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
Cooling power input kW 7.7+16.2 9.2+16.2 12.3+13.8 12.3+16.2
Heating power input kW 7.8+16.9 9.5+16.9 12.9+13.1 12.9+16.9
Cooling current
input
A 13.8+29.0 16.4+29.0 22.0+24.7 22.0+29.0
Heating current
input
A 13.9+30.2 17.0+30.2 23.1+23.4 23.1+30.2
Rated power input kW 13.50+27.41 18.18+27.41 26.30+26.85 26.30+27.41
Rated current A 24.1+49 32.5+49 47+48 47+49
Cooling operation
range
°C -5~52 -5~52 -5~52 -5~52
Heating operation
range
°C -30~24 -30~24 -30~24 -30~24
Refrigerant type - R410A R410A R410A R410A
Refrigerant charge kg 5.7+8.3 7+8.3 8+8 8+8.3
Maximum drive IDU
NO.
unit 56 59 63 64
Gas pipe mm Φ31.8 Φ38.1 Φ38.1 Φ38.1
Liquid pipe mm Φ19.05 Φ19.05 Φ19.05 Φ19.05
Outline dimensions
(W × D × H)
mm
930×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690
Packing dimensions
(W × D × H)
mm
1000×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855
Net weight kg 220+350 290+350 295+350 295+350
Gross weight kg 230+365 305+365 310+365 310+365
Model - GMV-1175WM/G-X GMV-1230WM/G-X GMV-1295WM/G-X GMV-1360WM/G-X
HP
HP
42
44
46
48
Combination mode
- 20+22 22+22 22+24 24+24
-
GMV-560WM/G-X+
GMV-615WM/G-X
GMV-615WM/G-X+
GMV-615WM/G-X
GMV-615WM/G-X+
GMV-680WM/G-X
GMV-680WM/G-X+
GMV-680WM/G-X
Cooling capacity kW 117.5 123.0 129.5 136.0
Heating capacity kW 132.0 138.0 145.5 153.0
Outdoor static
pressure
Pa 0/110 0/110 0/110 0/110
Noise (sound
pressure level)
dB(A) 65 65 65 65
Power -
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
Cooling power input kW 13.8+16.2 16.2+16.2 16.2+20.5 20.5+20.5
