Gree GMV-ND22C/A-T Service Manual

GREE GMV5 INDOOR UNIT SERVICE MANUAL
169
Motor and fan
Step
Diagram
Operation Procedure
4. Remove the volute
tongue.
●Remove the volute tongue.
5. Unscrew the outlet board.
●Use a screwdriver to unscrew the
outlet board and then remove the
board.
6. Remove the evaporator.
●Remove the evaporator.
7. Unscrew the motor
pressing board.
●Use a screwdriver to unscrew the
motor pressing board.
8. Remove the pressing
board and replace the
motor.
●Remove the pressing board and
replace the motor.
9. Screw the motor pressing
board.
●Use a screwdriver to screw the
motor pressing board.
