Gree GMV-ND22C/A-T Service Manual

GREE GMV5 INDOOR UNIT SERVICE MANUAL
210
Exploded View of
GMV-ND160T/A-T:
1
2
3
4
5
6
7
8
9
15
16
17
18
19
20
14
10
11
12
13
24
23
22
21
25
Note:
Details of this model are not issued yet. This list is made according to domestic sales details and
cannot be used to place order for accessories. It will be updated once the following details are issued.
No.
Name of part
For the following unit
Unit
Product Code
GMV-ND160T/A-T
CM500N0660
Part code
Quantity
1
Electric Box Assy
01394100298
1
2
Terminal Board
4201800002601
1
3
Terminal Board
42200000001501
1
4
Main Board
30226000027
1
5
Inductance
43128000014
1
6
Diversion Circle
10479401
1
7
Centrifugal Fan
10429401
1
8
Brushless DC Motor
15709400002
1
9
Water Tray Assy
01289400002
1
10
Evaporator Assy
01024100103
1
11
Filter Sub-Assy
07210029
1
12
Strainer
0741410000601
2
13
Electronic Expansio
n Valv
e
07334468
1
14
Shell Assy
01519400001
1
