GREE GMV5 INDOOR UNIT SERVICE MANUAL
214
NO
Model
GMV-ND28TS/A-T, GMV-ND36TS/A-T,
GMV-ND45TS/A-T, GMV-ND50TS/A-T
GMV-ND56TS/A-T
GMV-ND63TS/A-T
GMV-ND71TS/A-T
Qty
Product Code
CM500N0680
CM500N0690
CM500N0700
CM500N0710
CM500N0720
CM500N0730
CM500N0740
Part Name
Part Code
Part Code
15
Liquid Level Switch
43002400000501
43002400000501
1
16
Pump Drainpipe
04615487
04615487
1
17
Tube Exit Plate Assy
01344100056
01344100056
1
18
Water Pump
43138220
43138220
1
Tube-Exit Plate
01344100031
01344100031
1
19
Right Side Plate Sub-Assy
017038000049
017038000049
1
20
Evaporator Assy
01024100094
01024100093
1
21
Strainer
0741410000601
0741410000601
2
22
Electronic Expansion Valve
07334494
07334493
1
23
Terminal Board
42011106
42011106
1
24
Terminal Board
42200006000401
42200006000401
1
25
Main Board
30226000029
30226000029
1
26
Left Side Plate Sub-Assy
01314100104
01314100104
1
27
Sensor Sub-Assy
39008000013G
39008000013G
1
28
Drain Hose Sub-Assy
007008000001
007008000001
1
29
Remote Controller
30510589
1
Above data is subject to change without notice, pls reference the SP in global service website.
