MULTI VRF- INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
205
GMV-NR100A/A-D
NO.
Model
GMV-NX224P/A(X2.0)-M
Qty.
Product Code
CM800N3620
Part Name
Part Code
1
insulating board
` 75142201
1
2
Lower cover plate 1
` 01264100069
1
3
Top Cover Board Sub-assy
` 01262200019
1
4
Plastic Cover
` 26902209
4
5
Lower cover plate sub-assy 2
` 01262200017
1
6
Evaporator Assy
` 01024100166
1
7
Current Divider
` 0722443501
1
8
Strainer
` 0721200101
2
9
Electronic Expansion Valve
` 07334468
1
10
Electric Expand Valve Fitting
` 4304413205
1
11
Secondary Water Tray
` 26902205
1
12
Choke Plug
` 76718209
8
13
Main water Tray
` 26902204
1
14
Filter Sub-Assy
` 1172220201
1
15
Motor for Centrifugal Fan
` 1570220201
1
16
Fan Motor
` 15702245
1
17
Right Side Plate Sub-Assy
` 01312200017
1
18
Rear Side Plate Sub-Assy
` 01312200019
1
19
Blower Mounting Plate
` 01322200006
1
20
Electric cabinet board
` 01394100524
1
21
Capacitor CBB65
` 33000074
1
22
Terminal Board
` 4201115404
1
23
Main Board
` 30226000004
1
24
Terminal Board
' 4201800002601
1
25
Top Cover Plate Sub-Assy
` 01262200013
1
26
Left Side Plate Sub-Assy
` 01312200015
1
27
Sensor Sub-assy
` 39008000103G
1
28
Display Board
` 30296000040
1
GMV-NR112A/A-D
NO.
Model
GMV-NX224P/A(X2.0)-M
Qty.
Product Code
CM800N3620
Part Name
Part Code
1
insulating board
` 75142201
1
2
Lower cover plate 1
` 01264100069
1
3
Top Cover Board Sub-assy
` 01262200019
1
4
Plastic Cover
` 26902209
4
5
Lower cover plate sub-assy 2
` 01262200017
1
6
Evaporator Assy
` 01024100158
1
7
Current Divider
` 0722443501
1
8
Strainer
` 0721200101
2
9
Electronic Expansion Valve
` 07334468
1
10
Electric Expand Valve Fitting
' 4304413205
1
11
Secondary Water Tray
` 26902207
1
12
Choke Plug
` 76718209
8
13
Main water Tray
` 26902204
1
