MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
207
No.
Name of part
For the following unit
Unit
Product Code
GMV-ND22C/A-T
CM400N0140
GMV-ND28C/A-T
CM400N0070
GMV-ND36C/A-T
CM400N0080
GMV-ND45C/A-T
CM400N0150
GMV-ND50C/A-T
CM400N0090
Part code
Quantity
1
Front Panel Assy
` 20012756
1
2
Filter Sub-Assy
` 11122139
1
3
Front Case Assy
` 20012601
1
4
Air Louver(lower)
` 10512146
1
5
Air Louver(lower)
` 10512144
2
6
Water Tray
` 20182140
1
7
Axis(lower step motor)
` 10542034
1
8
Stepping Motor
` 1521210101
1
9
Water Tray Assy
` 20182141
1
10
Strainer
` 07213029
1
11
Evaporator Assy
` 01024100143
1
12
Electronic Expansion Valve
` 07334282
1
13
Electric Expand Valve Fitting
` 4304000102
1
14
Electric Box Assy
` 01394100489
1
15
Centrifugal Fan
` 01394100489
1
16
Brushless DC Motor
` 15704100012
1
17
Temperature Sensor
` 3900005910
1
18
Temperature Sensor
` 390000597
1
19
Temperature Sensor
` 3900019824
1
20
Let Side Plate
` 20052011
1
21
Rear Case
` 22202461
1
22
Top Side Plate
` 20052013
1
23
Right Side Plate
` 20052012
1
24
Diversion Circle
` 10371212
1
25
Louver Motor Sub-assy
' 00021100001
1
26
Swing Lever
` 10582096
2
27
Guide Louver (upper)
` 10512145
1
28
Air Louver(upper)
` 10512143
2
29
Shaft of Guide Louver
` 10542020
2
30
Rear Grill
` 01472024
1
