Gree GMV-ND22PLS/A-T Service Manual

MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
21
Net weight
kg
63.5
130
134
134
208
Notes:
①. a.Rated cooling capacity test conditions: fresh air inlet 35°C DB/28°C WB; connection pipe
length: 5 m, without height drop between units; The default air outlet temperature of the unit is
18°C.
②. b.Rated heating capacity test conditions: fresh air inlet 7°C DB/6°C WB; connection pipe length:
5 m, without height drop between units; The default air outlet temperature of the unit is 22°C.
DC Inverter Fresh Air Processing Indoor
Model
GMV-NDX224P/A-T
GMV-NDX280P/A-T
Horse Power
HP
8
10
Cooling capacity
kW
22.4
28.0
Heating capacity
kW*
1
16.0
20.0
kW*
2
20.0
22.0
Air volume
m
3
/h
2000/2000~3500
2500/2000~3500
Static pressure (Pa)
Standard
200
200
Optional
50~270
50~280
Rated power input
W
760
860
Rated current input
A
4.3
4.9
Cooling power input
W
400
520
Cooling current input
A
2.5
3.1
Heating power input
W
400
520
Heating current input
A
2.5
3.1
Minimum line current
A
6
6
Maximum fuse current
A
10
10
Sound pressure level
dB(A)
50
51
Power supply
220-240V 1 phase ~50Hz
208-230V 1 phase ~60Hz
Piping diameter
Liquid pie
mm
Φ9.52
Φ9.52
Gas pipe
mm
Φ19.05
Φ22.2
Drain pipe
Outer diameter ×
Wall thickness
mm
Φ30×1.5
Φ30×1.5
Dimensions
W×D×H
mm
1483×791×385
1483×791×385
Net weight
kg
82
82
Note：
①. Rated cooling capacity test conditions: indoor 35°C DB/28°C WB, outdoor 35°C DB; connection
pipe length: 7.5m, without height drop between units. The default air outlet temperature of the
unit is 18°C.
②. Rated heating capacity test conditions: *1:indoor 7°C DB, outdoor 7°C DB/6 °C WB,*2: indoor -
7°C DB, outdoor -7°C DB/RH80%; connection pipe length: 7.5m, without height drop between
units. The default air outlet temperature of the unit is 22°C.
③. In the column of “Air Volume”: The figure before “/” indicates the default air Volume of unit before
delivery, and the figures after indicate the adjustable air Volume range of unit.
④. The noise value marked in the nameplate is tested under rated condition, which is defaulted as
speed 08 under static pressure of 200Pa. The noise in the highest speed may increase by about
