Gree GMV-ND28C/A-T Service Manual

MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
173
No.
Name of part
For the following unit
For the following unit
Unit
Product Code
Unit
Product Code
GMV-ND45T/A-T
CM500N0400
GMV-ND56T/A-T
CM500N0420
GMV-ND50T/A-T
CM500N0410
GMV-ND63T/A-T
CM500N0430
/
/
GMV-ND71T/A-T
CM500N0440
/
/
GMV-ND80T/A-T
CM500N0450
Part code
Quantity
Part code
Quantity
4
Left Side Plate Assy
'01302740
1
'01302715
1
5
Front Side Plate assy
'01302717
1
'01302718
1
6
Base Plate Assy
'01222701
1
'01222701
1
7
Rear Side Plate Assy
'01302719
1
'01302714
1
8
Brushless DC Motor
'15704100007
1
'15709400004
1
9
Centrifugal Fan
'10312721
1
'10312705
1
10
Humidity Sensor
/
0
/
0
11
Filter Sub-Assy
'/
0
0
0
12
Strainer
'07415200002
1
'0741410000601
2
13
Electronic Expansion Valve
'07334463
1
'07334466
1
14
Drain Hose Sub-Assy
'05232050
1
'05232702
1
15
Water Tray Assy
'01289400013
1
'01289400013
1
16
Diversion Circle
'10372701
1
'10372701
1
17
Terminal Board
'4201800002601
1
'4201800002601
1
18
Terminal Board
'42011222
1
'42011222
1
19
Electric Box Assy
'01394100209
1
'01394100209
1
20
Main Board
'30226000029
1
'30226000029
1
21
Evaporator Assy
'01024100114
1
'01024100115
1
22
Sensor Sub-assy
'39008000013G
1
'39008000013G
1
23
Water Pump
'43130324
1
'43130324
1
24
Water Pump Assy
'15404100046
1
01332752
1
25
Water Level Switch
'45020216
1
'45020216
1
26
Pump Drainpipe
'05232721
1
'05230026
1
27
Right Side Plate Assy
'01302710
1
'01302716
1
28
Remote Controller
'30510589
1
'30510589
1
Above data is subject to change without notice,pls reference the SP in global service website.
