Gree GMV-ND28C/A-T Service Manual

MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
175
No.
Name of part
For the following unit
Unit
Product Code
GMV-ND90T/A-T
CM500N0460
GMV-ND100T/A-T
CM500N0470
GMV-ND112T/A-T
CM500N0480
GMV-ND125T/A-T
CM500N0480
GMV-ND140T/A-T
CM800N0550
Part code
Quantity
5
Front Side Plate assy
'01302713
1
6
Base Plate Assy
'01222701
1
7
Rear Side Plate Assy
'01302709
1
8
Brushless DC Motor
'15709400003
1
9
Centrifugal Fan
'10310101
1
10
Humidity Sensor
0
0
11
Filter Sub-Assy
0
0
12
Electronic Expansion
Valve
'07334468
1
13
Strainer
'0741410000601
2
14
Drain Hose Sub-Assy
'05232702
1
15
Water Tray Assy
'01289400013
1
16
Diversion Circle
'10372722
1
17
Terminal Board
'4201800002601
1
18
Terminal Board
'42011222
1
19
Electric Box Assy
'01394100209
1
20
Main Board
'30226000029
1
21
Evaporator Assy
'01024100116
1
22
Sensor Sub-assy
'39008000012G
1
23
Water Pump
'43130324
1
24
Water Pump Assy
'15404100044
1
25
Water Level Switch
'45020216
1
26
Pump Drainpipe
'05230026
1
27
Right Side Plate Assy
'01302712
1
28
Remote Controller
'30510589
1
Above data is subject to change without notice,pls reference the SP in global service website.
