Gree GMV-ND28TD/A-T - Page 134

MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
130
Motor and fan
Step
Diagram
Operation Procedure
6. Replace the
motor with a new
one.
●Replace the motor with a new one.
7. Screw the
motor.
●Use a screwdriver to screw the
motor.
8. Install and
screw the
centrifugal fan.
●Install the centrifugal fan and use a
wrench to screw the centrifugal fan.
9. Install and
screw the water
tray.
Loosen the
screws
●Use a screwdriver to screw the
water tray
