MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
23
Heating current input
A
0.3
0.3
0.3
0.3
0.5
*Minimum line current
A
0.38
0.38
0.38
0.38
0.63
*Maximum fuse current
A
6
6
6
6
6
Sound pressure level
dB(A)
33
33
35
35
37
Power supply
220-240V 1 phase ~50Hz/208-230V 1 phase ~60Hz
Piping interface
Liquid pipe
mm
Φ6.35
Φ6.35
Φ9.52
Φ9.52
Φ9.52
Gas pipe
mm
Φ12.7
Φ12.7
Φ15.9
Φ15.9
Φ15.9
Drain pipe
External
diameter ×
thickness
mm
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Dimensions
W×D×H
mm
1010×450
×200
1010×45
0×200
1010×45
0×200
1010×45
0×200
1310×450
×200
Net weight
Main body
kg
23.5
23.5
24.5
24.5
30.5
Notes:
①. a.Rated cooling capacity test conditions: indoor 27°C DB/19°C WB, outdoor 35°C DB;
connection pipe length: 5 m, without height drop between units
②. b.Rated heating capacity test conditions: indoor 20°C DB, outdoor 7°C DB/6 °C WB; connection
pipe length: 5 m, without height drop between units
③. c.In the column of “Unit external static pressure”: The figure before “/” indicates the default
external static pressure of unit before delivery, and the figures after indicate the adjustable static
pressure range of unit.
3.11 Air Handler type Indoor Unit
Model
GMV-
NR71A/A-D
GMV-
NR90A/A-D
GMV-
NR100A/A-
D
GMV-
NR112A/A-D
GMV-
NR140A/A-D
Horse Power
HP
2.5
3.0
3.5
4.0
5.0
Cooling capacity
kW
7.1
9.0
10.0
11.2
14.0
Heating capacity
kW
8.0
10.0
11.0
12.5
15.0
Air volume
m
3
/h
1600
1700
1900
2250
2400
Cooling power input
W
215
270
370
430
550
Cooling current input
A
1.10
1.35
2.00
2.00
2.50
Heating power input
W
215
270
370
430
550
Heating current input
A
0.4
0.4
0.4
0.5
0.5
*Minimum line current
A
1.10
1.35
2.00
2.00
2.50
