Gree GMV-ND28TD/A-T - Compact 4-Way Cassette Type

MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
16
Panel
dimensions
W×D×H
mm
950×
950×65
950×
950×65
950×
950×65
950×950
×65
950×950
×65
950×950
×65
1040×
1040×65
Net weight
Main
body
kg
26.5
32.5
32.5
32.5
32.5
32.5
46.5
Panel
kg
7
7
7
7
7
7
7.5
Notes:
① Rated cooling capacity test conditions: indoor 27°C DB/19°C WB, outdoor 35°C DB; connection
pipe length: 5 m, without height drop between units.
② Rated heating capacity test conditions: indoor 20°C DB, outdoor 7°C DB/6 °C WB; connection
pipe length: 5 m, without height drop between units.
3.5 Compact 4-way Cassette Type
Model
GMV-
ND22T/B-
T
GMV-
ND28T/B-T
GMV-
ND36T/B-T
GMV-
ND45T/B-T
GMV-
ND50T/B-T
GMV-
ND56T/B-T
Horse Power
HP
1
1
1.5
2
2
2
Cooling capacity
kW
2.2
2.8
3.6
4.5
5.0
5.6
Heating capacity
kW
2.5
3.2
4.0
5.0
5.6
6.3
Air volume
m
3
/h
600
600
600
700
700
700
Cooling power input
W
35
35
35
45
45
45
Cooling current input
A
0.4
0.4
0.4
0.5
0.5
0.5
Heating power input
W
35
35
35
45
45
45
Heating current input
A
0.4
0.4
0.4
0.5
0.5
0.5
*Minimum line current
A
0.5
0.5
0.5
0.63
0.63
0.63
*Maximum fuse current
A
6
6
6
6
6
6
Sound pressure level
dB(A
)
41
41
41
45
45
45
Power supply**
220-240V 1 phase ~50Hz/208-230V 1 phase ~60Hz
Piping
interface
Liquid
pipe
mm
Φ6.35
Φ6.35
Φ6.35
Φ6.35
Φ9.52
Φ9.52
Gas
pipe
mm
Φ9.52
Φ9.52
Φ12.7
Φ12.7
Φ12.7
Φ15.9
Drain pipe
Extern
al
diamet
er ×
Thickn
ess
mm
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Main body
dimensions
W×D×
H
mm
596×596
×240
596×596×2
40
596×596×2
40
596×596×2
40
596×596×2
40
596×596×2
40
