MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
160
No.
Name of part
For the following unit
For the following unit
Unit
Product Code
Unit
Product Code
GMV-ND224PH/A-
T
CM800N3721
GMV-ND280PH/A-
T
CM800N3731
Part code
Quantity
Part code
Quantity
1
Front Side Plate Sub-Assy
'01314627
1
`01314315
1
2
Centrifugal fan assy
` 15404100051
1
`15404100061
1
3
Brushless DC Motor
'15704100009
1
`15704100009
1
4
Motor
'15705306
1
`15704118
1
5
Motor
'15705307
1
`1570411801
1
6
Lower Cover Plate Sub-Assy
'01265357
1
`01264213
1
7
Right Side Plate Assy
'01314321
1
`01314312
1
8
Front Side Plate assy 2
'01314627
1
`01314315
1
9
Seal Of Connection Pipe sub-
assy
`01494709
1
`01494709
1
10
Main Board
` 30226000064
1
`30221000023
1
11
Terminal Board
` 4201800002601
1
`4201800002601
1
12
Terminal Board
` 42010259
1
`42010259
1
13
Reactor
`43130189
1
`43130189
1
14
Main Board
` 30221000018
1
`30226000064
1
15
Radiator
` 49018000068
1
`49018000068
1
16
Electric Box Assy
' 01394100450
1
`01394100450
1
17
Electric Expand Valve Fitting
'4304413205
1
`4304413205
1
18
Strainer
'0741410000601
1
`0741410000601
1
19
Electronic Expansion Valve
'07331139
1
` 07331139
1
20
filter guide groove
'02284107
2
` 02284105
2
21
Filter Sub-Assy
' 11725211
2
`11724102
2
22
Evaporator Assy
01024100119
1
` 01024100124
1
23
Hook
'02112466
4
02112466
4
24
Top Cover Board Sub-assy
'01265359
1
01264215
1
25
Water Tray Assy
'01284620
1
01284306
1
26
Choke Plug of Water Pipe
'76712454
2
76712454
2
27
Right Side Plate Sub-Assy
`01314321
1
01314312
1
28
Right Side Plate Sub-Assy
`01314100086'
1
01314100088
1
29
Sensor Sub-assy
'39008000103G
1
39008000103G
1
30
Display Board
' 30296000040
1
30296000040
1
Above data is subject to change without notice,pls reference the SP in global service website.
