MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
162
No.
Name of part
For the following unit
For the following unit
Unit
Product Code
Unit
Product Code
GMV-
ND22PLS/A-T
CM800N3370
GMV-
ND32PLS/A-T
CM800N3390
GMV-
ND25PLS/A-T
CM800N3380
GMV-
ND36PLS/A-T
CM800N3500
GMV-
ND28PLS/A-T
CM800N3490
/
/
Part code
Quantity
Part code
Quantity
10
Main Board
'30226000029
1
'30226000029
1
11
Terminal Board
'42011106
1
'42011106
1
12
Terminal Board
'4201800002601
1
'4201800002601
1
13
Electric Box Cover
'01424100035
1
'01424100035
1
14
Sealplate Sub-assy (drainage)
'01495315
1
'01495315
1
15
Sealplate Sub-assy (outlet)
'01495316
1
'01495316
1
16
Left Side Plate Assy
'01315200087
1
'01315200087
1
17
Filter
'0741410000601
2
'0741410000601
2
18
Water Level Switch
` 45020216
1
'45020216
1
19
Electronic Expansion Valve
'07334463
1
'07334463
1
20
Cover of Air Outlet
'01265298
1
'01265298
1
21
Water Pump
'43130324
1
'43130324
1
22
Air Outlet Frame Assy
'01374636
1
'01374636
1
23
Sealplate Sub-Assy
'01495317
1
'01495317
1
24
Filter Sub-Assy
'11725209
1
'11128633
1
25
Evaporator Assy
`01024100108
1
'01024100109
1
26
Top Cover Board Assy
'01265325
1
'01265325
1
27
Supporter
'01895225
2
'01895225
2
28
Water Tray Assy
'01285332
1
'01285332
1
29
Bottom Cover Plate
'01265299
1
'01265299
1
30
Choke Plug of Drain Pipe
'76815214
2
'76815214
2
31
Right Side Plate Assy
'01315335
1
'01315335
1
32
Front Volute Casing
'26905205
2
'26905205
2
33
Fan Motor
'15704100001
1
'15704100001
1
34
Sensor Sub-Assy
'39004168G
1
'39004168G
1
35
Drain Hose Sub-Assy
` 05232050
1
` 05232050
1
36
Display Board
` 30296000040
1
` 30296000040
1
Above data is subject to change without notice,pls reference the SP in global service website.
