Gree GMV-ND28TD/A-T - Page 187

MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
183
No.
Name of part
For the following unit
For the following unit
Unit
Product Code
Unit
Product Code
GMV-ND45TD/A-
T
CM502N0120
GMV-ND50TD/A-
T
CM502N0130
Part code
Quantity
Part code
Quantity
1
Remote Controller
'30510589
1
'30510589
1
2
Drain Hose Sub-Assy
'05232050
1
'05232050
1
3
Temperature Sensor
'39008000079G
1
'39008000079G
1
4
Humidity Sensor Cover
0
0
0
0
5
Humidity Sensor
0
0
0
0
6
Water Level Switch
'4501270301
1
'4501270301
1
7
Water Pump Assy
'15404100005
1
'15404100005
1
8
Pump Drainpipe
'26905288
1
'26905288
1
9
Water Pump
'4313822001
1
'4313822001
1
10
Hook
'02112466
4
'02112466
4
11
Right Side Plate Sub-Assy
'01314100023
1
'01314100023
1
12
Tube Exit Plate Assy
'01344100020
1
'01344100020
1
13
Electric Box Assy
'01394100396
1
'01394100396
1
14
Main Board
'30226000029
1
'30226000029
1
15
Terminal Board
'4201026603
1
'4201026603
1
16
Terminal Board
'4201800002601
1
'4201800002601
1
17
Main Board
'30226000029
1
'30226000029
1
18
Brushless DC Motor
'1501214301
1
'1501214301
1
19
Strainer
' 0741410002501
1
' 0741410002501
1
20
Electronic Expansion Valve
'07334494
1
'07334494
1
21
Filter
'07415210
1
'07415210
1
22
Filter Sub-Assy
0
0
0
0
23
Evaporator Assy
'01024100014
1
'01024100014
1
24
Water Tray Sub-Assy
'01284100011
1
'01284100011
1
25
Cross Flow Fan
'10454100001
1
'10454100001
1
26
Helicoid Tongue sub-assy
'02224100007
1
'02224100007
1
27
O-Gasket of Cross Fan
Bearing
'76512203
1
'76512203
1
28
Chassis Assy
'01194100007
1
'01194100007
1
29
Left Side Plate Sub-Assy
'01314100022
1
'01314100022
1
Above data is subject to change without notice,pls reference the SP in global service website.
