MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
203
GMV-NR140A/A-D
NO.
Model
GMV-NX224P/A(X2.0)-M
Qty.
Product Code
CM800N3620
Part Name
Part Code
1
insulating board
'75142201
1
2
Lower cover plate 1
01264100065
1
3
Top Cover Board Sub-assy
'01262200024
1
4
Plastic Cover
'26902209
4
5
Lower cover plate sub-assy 2
'01262200026
1
6
Evaporator Assy
'01024100159
1
7
Current Divider
'0722443501
1
8
Strainer
'0721200101
2
9
Electronic Expansion Valve
'07334468
1
10
Electric Expand Valve Fitting
'4304413205
1
11
Secondary Water Tray
'26902207
1
12
Choke Plug
76718209
8
13
Main water Tray
'26902206
1
14
Filter Sub-Assy
'11722202
1
15
Motor for Centrifugal Fan
'1570220201
1
16
Fan Motor
'15702237
1
17
Right Side Plate Sub-Assy
'01312200026
1
18
Rear Side Plate Sub-Assy
'01312200028
1
19
Blower Mounting Plate
'01322200010
1
20
Electric cabinet board
'01394100522
1
21
Capacitor CBB65
'3300008111
1
22
Terminal Board
'4201115404
1
23
Main Board
'30226000004
1
24
Terminal Board
'4201800002601
1
25
Top Cover Plate Sub-Assy
'01262200028
1
26
Left Side Plate Sub-Assy
'01312200030
1
27
Sensor Sub-assy
'39008000103G
1
28
Display Board
'30296000040
1
GMV-NR71A/A-D、
NO.
Model
GMV-NX224P/A(X2.0)-M
Qty.
Product Code
CM800N3620
Part Name
Part Code
1
insulating board
' 75142201
1
2
Lower cover plate 1
` 01264100070
1
3
Top Cover Board Sub-assy
` 01262200007
1
4
Plastic Cover
` 26902209
4
5
Lower cover plate sub-assy 2
` 01262200009
1
6
Evaporator Assy
` 01024100162
1
7
Current Divider
` 072241303
1
8
Strainer
` 0721200101
2
9
Electronic Expansion Valve
` 07334466
1
10
Electric Expand Valve Fitting
` 4304413205
1
11
Secondary Water Tray
` 26902200002
1
12
Choke Plug
` 76718209
8
13
Main water Tray
` 26902200001
1
