Gree GMV-ND45T/A-T

MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
24
*Maximum fuse current
A
6
6
6
6
6
Sound pressure level
dB(A
)
50
51
52
52
55
Power supply*
208-230V 1 phase ~60Hz
Piping
interface
Liquid pipe
mm
Φ9.52
Φ9.52
Φ9.52
Φ9.52
Φ9.52
Gas pipe
mm
Φ15.9
Φ15.9
Φ15.9
Φ15.9
Φ15.9
Drain pipe
External
diameter ×
Thickness
mm
Φ19×2.5
Φ19×2.5
Φ19×2.5
Φ19×2.5
Φ19×2.5
Main body
dimensions
W×D×H
mm
460×540
×1105
460×540
×1105
540×540
×1224
540×540
×1224
630×540
×1224
Panel
dimensions
W×D×H
mm
517×620×11
70
517×620×11
70
597×620×12
89
597×620×128
9
687×621×129
5
Net weight
Main body
kg
54
57
57
68
78
Notes:
①. a.Rated cooling capacity test conditions: indoor 27°C DB/19°C WB, outdoor 35°C DB;
connection pipe length: 5 m, without height drop between units.
②. b.Rated heating capacity test conditions: indoor 20°C DB, outdoor 7°C DB/6 °C WB; connection
pipe length: 5 m, without height drop between units.
3.12 Console Type Indoor Unit
Model
GMV-
ND22C/A-T
GMV-
ND28C/A-T
GMV-
ND36C/A
-T
GMV-
ND45C/A-
T
GMV-
ND50C/A-T
Horse Power
HP
1
1
1.5
2
2
Cooling capacity
kW
2.2
2.8
3.6
4.5
5.0
Heating capacity
kW
2.5
3.2
4.0
5.0
5.5
Air volume
m
3
/h
450
500
600
630
650
Cooling power input
W
15
15
20
40
40
Cooling current input
A
0.17
0.17
0.25
0.25
0.4
Heating power input
W
15
15
20
40
40
Heating current input
A
0.17
0.17
0.25
0.25
0.4
*Minimum line current
A
0.16
0.16
0.16
0.16
0.16
*Maximum fuse current
A
6
6
6
6
6
Sound pressure level
dB(A)
36
38
40
43
46
Power supply
220-240V 1 phase ~50Hz/208-230V 1 phase ~60Hz
Piping
interface
Liquid pipe
mm
6.35
6.35
6.35
6.35
6.35
Gas pipe
mm
9.52
9.52
12.7
12.7
12.7
