Gree GMV-ND71G/B4B-T User Manual

Multi Variable Air Conditioners Wall Mounted Type Indoor Unit
7
Material Type
Total Length L (m/feet) of
Communication Cable
between Indoor Unit and
Indoor (Outdoor) Unit
Wire size
(mm
2
/AWG)
Material
Standard
Remarks
Light/Ordinary
polyvinyl
chloride
sheathed cord.
(60227 IEC 52
/60227 IEC 53)
L≤1000m
(L≤3280-5/6feet)
≥2×0.75
(≥2×AWG18)
IEC
60227-5-2007
1. If the wire diameter is enlarged
to 2×1 mm
2
(2×AWG16), the total
communication line length can
reach 1500 m (4921-1/4feet).
2. The cord shall be Circular cord
(the cores shall be twisted
together).
3. If unit is installed in places with
intense magnetic field or strong
interference, it is necessary to
use shielded wire.
3.4 Wiring Requirements
Model
Power Cord
Size
Air Switch
Capacity
(A)
Minimum
Sectional Area
of Ground
Wire(mm
2
)
Minimum
Sect
ional Area
of Power
Cord(mm
2
)
GMV-ND15G/B6B-T,GMV-ND18G/B6B-T
GMV-ND22G/B6B-T,GMV-ND28G/B6B-T
GMV-ND36G/B6B-T,GMV-ND45G/B6B-T
GMV-ND50G/B6B-T,GMV-ND56G/B6B-T
GMV-ND63G/B6B-T,GMV-ND71G/B6B-T
220-240V ~
50Hz
208-230V ~
60Hz
6 1 1
GMV-ND15G/B4B-T,GMV-ND18G/B4B-T
GMV-ND22G/B4B-T,GMV-ND28G/B4B-T
GMV-ND36G/B4B-T,GMV-ND45G/B4B-T
GMV-ND50G/B4B-T,GMV-ND56G/B4B-T
GMV-ND63G/B4B-T,GMV-ND71G/B4B-T
GMV-ND80G/B4B-T,GMV-ND90G/B4B-T
GMV-ND100G/B4B-T
220-240V ~
50Hz
208-230V ~
60Hz
6 1 1
GMV-ND22G/C4B-T,GMV-ND28G/C4B-T
GMV-ND36G/C4B-T,GMV-ND45G/C4B-T
GMV-ND50G/C4B-T,GMV-ND56G/C4B-T
GMV-ND63G/C4B-T,GMV-ND71G/C4B-T
220-240V ~
50Hz
208-230V ~
60Hz
6 1 1
GMV-ND22G/C2B-T,GMV-ND28G/C2B-T
GMV-ND36G/C2B-T,GMV-ND45G/C2B-T
GMV-ND50G/C2B-T,GMV-ND56G/C2B-T
GMV-ND63G/C2B-T,GMV-ND71G/C2B-T
220-240V ~
50Hz
208-230V ~
60Hz
6 1 1
GMV-ND22G/D2B-T,GMV-ND28G/D2B-T
GMV-ND36G/D2B-T,GMV-ND45G/D2B-T
GMV-ND50G/D2B-T,GMV-ND56G/D2B-T
GMV-ND63G/D2B-T,GMV-ND71G/D2B-T
220-240V ~
50Hz
208-230V ~
60Hz
6 1 1
NOTES!
① Use copper wire only as unit’s power cord. Operating temperature should be within its
rated value.
② If the power cord is more than 15m, please increase properly the sectional area of
power cord to avoid overload, which may cause accident.
③ Above selection requirements: Power cord size is based on BV single-core wire
(2~4pc) at 40°C ambient temperature when laying across plastic pipe. Air switch is D
type and used at 40°C.If actual installation condition varies, please lower the capacity
appropriately according to the specifications of power cord and air switch provided by
