Multi Variable Air Conditioners Wall Mounted Type Indoor Unit
4
If there are any
abnormal circumstances
(such as burning smell,
etc.), please turn off the
unit and cut off the main
power supply
immediately, and then
contact Gree appointed
service center. If those
abnormal circumstances
still exit, the unit may be
damaged and it may
lead to electric shock or
Do not repair the unit by
yourself. Wrong
maintenance may cause
electric shock or fire
hazard. Please contact
Gree appointed service
center for help.
Any personal injury or property loss caused by improper installation, improper debug,
unnecessary repair or not following the instructions of this manual should not be the
responsibility of Gree Electric Appliances, Inc. of Zhuhai.
2 Product Introduction
2.1 Outline of the Unit and Main Parts
Fig 2.1
NOTE
!
The appearances will be different by the different models of air conditioners.
No. Part Name No. Part Name
①
Surface panel
④
Guide louver
②
Filter
⑤
Drain pipe
③
Wiring cover — —
2.2 Rated Operating Condition
Item
Indoor Condition Outdoor Condition
DBTemperature°C WBTemperature°C DBTemperature°C WBTemperature°C
Rated Cooling 27 19 35 24
Rated Heating 20 15 7 6
