9
GMV5 HR HEAT RECOVERY
VRF Units Technical Sales Guide
Outdoor Units_Heat Recovery To n 12 14
Model - GMV-Q144WM/B1-F(U) GMV-Q168WM/B1-F(U)
Module combination - GMV-Q144WM/B1-F(U) GMV-Q168WM/B1-F(U)
Pipe
Connection
Low pressure Gas Pipe Size
mm 28.60 28.60
in. 1 1/8 1 1/8
high pressure gas pipe Size
mm 22.20 22.20
in. 7/8 7/8
Liquid Pipe Size
mm 12.70 5.90
in. 1/2 5/8
Dimensions
(width×
depth×
height)
External Dimension
mm 1340×765×1605 1340×765×1740
in. 52-3/4×30-1/8×63-1/5 52-3/4×30-1/8×68-1/2
Packaging Dimension
mm 1420×840×1775 1420×840×1910
in. 55-7/8×33-1/8×69-7/8 55-7/8×33-1/8×75 1/4
Weight
Net Weight
kg 370 395
lbs. 816 871
Gross Weight
kg 385 411
lbs. 849 906
Maximum qty of connected indoor units unit 23 29
Protection
Devices
High Pressure Protection High pressure sensor, High pressure switch
Compressor /Fan Over-current protection, Over-heat protection
Inverter Over-current protection, Over-heat protection, High/ Low voltage protection,
Remark
① .
Rating conditions:
Cooling: indoor 26.7°C (80°F) D.B./19.4°C(67°F)W.B. outdoor: 35°C(95°F)D.B.
Heating: indoor 21.1°C (70°F)D.B. outdoor: 8.3°C (47°F)D.B./6.1°C(43°F)W.B
② .
It refers to the operation power of compressor under ARI test conditions (Condensing temp. 130°F; Evaporating
temp.45°F; Return gas temp.65°F; Liquid temp.115°F) at 60Hz.
③ .
Oil charge includes the total oil amount of outdoor units, residual oil amount of compressor and oil separate tank.
When replacing the compressor or oil separate tank, only the corresponding required oil amount shall be charged
