7
GMV5 HR HEAT RECOVERY
VRF Units Technical Sales Guide
Outdoor Units_Heat Recovery To n 6 8 10
Model - GMV-Q72WM/B-F(U) GMV-Q96WM/B-F(U) GMV-Q120WM/B-F(U)
Module combination - GMV-Q72WM/B-F(U) GMV-Q96WM/B-F(U) GMV-Q120WM/B-F(U)
Refrigerant
Refrigerant Type - R410A R410A R410A
Refrigerant Charge Volume
kg 9.6 11.2 11.7
lbs. 21.16 24.69 25.79
Control - EXV EXV EXV
Pipe
Connection
Low pressure Gas Pipe Size
mm 19.05 22.2 28.6
in. 3/4 7/8 1 1/8
high pressure gas pipe Size
mm 15.9 19.05 22.2
in. 5/8 3/4 7/8
Liquid Pipe Size
mm 9.52 9.52 12.7
in. 3/8 3/8 1/2
Dimensions
(width×
depth×
height)
External Dimension
mm 1340×765×1605 1340×765×1605 1340×765×1605
in. 52-3/4×30-1/8×63-1/5 52-3/4×30-1/8×63-1/5 52-3/4×30-1/8×63-1/5
Packaging Dimension
mm 1420×840×1775 1420×840×1775 1420×840×1775
in. 55-7/8×33-1/8×69-7/8 55-7/8×33-1/8×69-7/8 55-7/8×33-1/8×69-7/8
Weight
Net Weight
kg 302 310 360
lbs. 666 683 794
Gross Weight
kg 317 325 375
lbs. 699 716 827
Maximum qty of connected indoor units unit 13 16 19
Protection
Devices
High Pressure Protection High pressure sensor, High pressure switch
Compressor /Fan Over-current protection, Over-heat protection
Inverter Over-current protection, Over-heat protection, High/ Low voltage protection,
Remark
① .
Rating conditions:
Cooling: indoor 26.7°C (80°F) D.B./19.4°C(67°F)W.B. outdoor: 35°C(95°F)D.B.
Heating: indoor 21.1°C (70°F)D.B. outdoor: 8.3°C (47°F)D.B./6.1°C(43°F)W.B
② .
It refers to the operation power of compressor under ARI test conditions (Condensing temp. 130°F; Evaporating
temp.45°F; Return gas temp.65°F; Liquid temp.115°F) at 60Hz.
③ .
Oil charge includes the total oil amount of outdoor units, residual oil amount of compressor and oil separate tank.
When replacing the compressor or oil separate tank, only the corresponding required oil amount shall be charged
