Gree GMV6 Series User Manual

Gree GMV6 DC Inverter VRF Units Service Manual
308
No.
Name
Code
Vulnerable part *
Qty
23
Electromagnetic Valve
43000072
*
1
24
Strainer
07415200002
*
2
25
Oil Separator
035028060002
*
1
26
Cut off Valve
0733410005301
*
1
27
Cut off Valve
0733410001401
*
1
28
Strainer
07222025
*
1
29
Electromagnetic Valve
072008000005
*
3
30
Gas-liquid Separator
035027060004
*
1
31
Nozzle for Adding Freon
06130002
*
1
32
Electric Box Assy
100002071717
*
1
33
Electric Box Assy
100002071694
*
1
34
Transformer
43118000023
*
1
35
Cover Plate
012035000246P
1
36
Left Front Panel
012062000017P
1
37
Left Front Panel
012062000016P
1
38
Right Panel
012167000014P
1
39
4 Way Valve Coil
072010060002
*
1
40
Magnet Coil (electromagnetic valve)
07200106000811
*
1
41
Magnet Coil (electromagnetic valve)
072001060010
*
1
42
Magnet Coil (electromagnetic valve)
072001060007
*
1
43
Magnet Coil (electromagnetic valve)
072001060006
*
1
44
Magnet Coil (electromagnetic valve)
07200106000812
*
1
45
Electric Expand Valve Fitting
4304413274
*
1
46
Electric Expand Valve Fitting
4304413269
*
1
47
Electric Expand Valve Fitting
4304413220
*
1
48
Electric Expand Valve Fitting
072002000011
*
1
49
Electrical Heater(Compressor)
7651521243
*
1
50
Electrical Heater(Compressor)
7651521244
*
1
51
Pressure Sensor
32210103
*
1
52
Pressure Sensor
32218000008
*
1
53
Sensor Sub-Assy
390002060038
*
1
54
Compressor and Fittings
009001060576
*
2
55
Bidirection Strainer
07220016
*
1
56
Silencer
07245008
*
2
57
Pressure Protect Switch
4602000911
*
1
58
One Way Valve
07333700032
*
2
59
Pressure Protect Switch
4602000910
*
1
60
Electronic Expansion Valve
43044100190
*
2
61
Right Side Plate Sub-Assy
017038060026P
1
62
Terminal Board
42200006000303
*
1
63
Terminal Board
42200006005403
*
1
64
Main Board
300027061456
*
1
65
Reactor
45000406000901
*
2
66
Filter Board
300020060006
*
2
67
Drive Board
300078060206
*
2
68
Radiator
4901800008002
*
2
69
Radiator
49018000088
*
2
70
Main Board
300027000583
*
2
71
Radiator
43003406003301
*
1
Above data is subject to change without notice,pls reference the SP in global service website.
