10
Technical Information
Service Manual
Parameter Unit Value
Model GPC08AH-K3NNC5C GPC09AH-K3NNC5C
Product Code CK010019800 CK010019900
Power
Supply
Rated Voltage V
～
220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Cooling Capacity Btu/h 8000 9000
Heating Capacity Btu/h / /
Cooling Power Input W 975 1100
Heating Power Input W / /
Cooling Power Current A 4.2 4.8
Heating Power Current A / /
Rated Input W 1100 1250
Rated Current A 4.60 5.80
Air Flow Volume(H/M/L) m
3
/h 330/300/250 330/300/250
Dehumidifying Volume L/h 0.75 0.75
EER Btu/w.h 8.21 8.18
COP Btu/w.h / /
SEER / /
HSPF / /
Application Area m
2
10-16 10-16
Climate Type T1 T1
Isolation I I
Moisture Protection
IPX0 IPX0
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 3.8 3.8
Permissible Excessive Operating Pressure for
the Suction Side
MPa 1 1
Throttling Method Capillary Capillary
Defrosting Method / /
Fuse A 3.15 3.15
Operation Temp
o
C 16~30 16~30
Ambient Temp (Cooling)
o
C 16~35 16~35
Ambient Temp (Heating)
o
C / /
Sound Pressure Level (H/M/L) dB (A) 56/54/52 56/54/52
Sound Power Level (H/M/L) dB (A) 66/64/62 66/64/62
Dimension (WXHXD) mm 300X807X375 300X807X375
Dimension of Carton Box (LXWXH) mm 562X352X835 562X352X835
Dimension of Package (LXWXH) mm 565X355X850 565X355X850
Net Weight kg 23.5 27
Gross Weight kg 28.5 32
Refrigerant R410A R410A
Refrigerant Charge kg 0.39 0.48
