11
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Compressor
Compressor Manufacturer/
Trademark
ZHUHAI LANDA COMPRESSOR
CO., LTD.
ZHUHAI LANDA COMPRESSOR
CO., LTD.
Compressor Model QXA-A086R130 QXA-B102T130
Compressor Oil
RB68EP POE(ZE-GLES RB68EP)
Compressor Type Rotary Rotary
L.R.A. A 15.5 19
Compressor RLA A 3.5 3.9
Compressor Power Input W 730 850
Overload Protector B155-150-241E UP3-21
Evaporator
Fan Type Centrifugal Centrifugal
Diameter Length(DXL) mm Φ146X108.5 Φ146X108.5
Fan Motor Speed(H/M/L) r/min 1250/1150/1050 1250/1150/1050
Output of Fan Motor W 45 45
Fan Motor RLA A 0.41 0.41
Fan Motor Capacitor μF 3.5 3.5
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 2-1.3 2-1.3
Coil Length (LXDXW) mm 377.5X25.4X266.7 377.5X25.4X266.7
Swing Motor Model / /
Output of Swing Motor W / /
Condenser
Fan Type Centrifugal Centrifugal
Fan Diameter mm Φ185X77 Φ185X77
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Rows-n Gap mm 2-1.4 2-1.4
Coil Length (LXDXW) mm 343X25.4X266.7 343X25.4X266.7
Fan Motor Speed rpm / /
Output of Fan Motor W / /
Fan Motor RLA A / /
Fan Motor Capacitor μF / /
To Next Page
