Gree GPC07AH-K3NNC3D User Manual

12
Technical Information
Service Manual
Parameter Unit Value
Model GPC07AH-K3NNC3D GPC08AH-K3NNC3D
Product Code CK010020900 CK010021000
Power
Supply
Rated Voltage V
～
220-240 220-240
Rated Frequency Hz 50 50
Phases
1 1
Cooling Capacity Btu/h 7000 8000
Heating Capacity Btu/h / /
Cooling Power Input W 790 900
Heating Power Input W / /
Cooling Power Current A 3.5 4.2
Heating Power Current A / /
Rated Input W 950 1130
Rated Current A 4.0 4.6
Air Flow Volume(H/M/L) m
3
/h 330/300/250 330/300/250
Dehumidifying Volume L/h 0.75 0.75
EER Btu/w.h 8.86 8.89
COP Btu/w.h / /
SEER / /
HSPF / /
Application Area m
2
10-16 10-16
Climate Type T1 T1
Isolation I I
Moisture Protection IPX0 IPX0
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 3.8 3.8
Permissible Excessive Operating Pressure for
the Suction Side
MPa 1 1.7
Throttling Method Capillary Capillary
Defrosting Method / /
Fuse A 3.15 3.15
Operation Temp
o
C 16~30 16~30
Ambient Temp (Cooling)
o
C 16~35 16~35
Ambient Temp (Heating)
o
C / /
Sound Pressure Level (H/M/L) dB (A) 54/52/50 54/52/50
Sound Power Level (H/M/L) dB (A) 65/63/61 65/63/61
Dimension (WXHXD) mm 300X790X345 300X790X345
Dimension of Carton Box (LXWXH) mm 562X352X825 562X352X825
Dimension of Package (LXWXH) mm 565X355X840 565X355X840
Net Weight kg 24 24
Gross Weight kg 28 28
Refrigerant R410A R410A
Refrigerant Charge kg 0.48 0.46
