Gree GPC07AH-K3NNC3D User Manual

18
Technical Information
Service Manual
Parameter Unit Value
Model GPC09AH-K3NNC5D
Product Code CK010023800
Power
Supply
Rated Voltage V
～
220-240
Rated Frequency Hz 50
Phases 1
Cooling Capacity Btu/h 9000
Heating Capacity Btu/h /
Cooling Power Input W 1010
Heating Power Input W /
Cooling Power Current A 4.44
Heating Power Current A /
Rated Input W 1250
Rated Current A 5.8
Air Flow Volume(H/M/L) m
3
/h 330/300/250
Dehumidifying Volume L/h 0.95
EER Btu/w.h 8.91
COP Btu/w.h /
SEER /
HSPF /
Application Area m
2
12-18
Climate Type T1
Isolation I
Moisture Protection IPX0
Permissible Excessive Operating Pressure
for the Discharge Side
MPa 3.8
Permissible Excessive Operating Pressure
for the Suction Side
MPa 1.7
Throttling Method Capillary
Defrosting Method /
Fuse A 3.15
Operation Temp
o
C 16~30
Ambient Temp (Cooling)
o
C 16~35
Ambient Temp (Heating)
o
C /
Sound Pressure Level (H/M/L) dB (A) 56/54/52
Sound Power Level (H/M/L) dB (A) 66/64/62
Dimension (WXHXD) mm 300X807X375
Dimension of Carton Box (LXWXH) mm 562X352X835
Dimension of Package (LXWXH) mm 565X355X850
Net Weight kg 27
Gross Weight kg 31
Refrigerant R410A
Refrigerant Charge kg 0.48
