19
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Compressor
Compressor Manufacturer/Trademark
ZHUHAI LANDA COMPRESSOR CO., LTD.
Compressor Model
QXA-B102T130A
Compressor Oil
RB68EP
Compressor Type
Rotary
L.R.A. A 19.1
Compressor RLA A 3.9
Compressor Power Input W 830
Overload Protector HPA-318
Evaporator
Fan Type
Centrifugal
Diameter Length(DXL) mm Φ146X108.5
Fan Motor Speed(H/M/L) r/min 1250/1150/1050
Output of Fan Motor W 45
Fan Motor RLA A 0.41
Fan Motor Capacitor μF 3.5
Form Aluminum Fin-copper Tube
Pipe Diameter mm Φ7
Row-n Gap
mm
2-1.3
Coil Length (LXDXW)
mm 377.5X25.4X266.7
Swing Motor Model /
Output of Swing Motor W /
Condenser
Fan Type Centrifugal
Fan Diameter mm Φ185X77
Form Aluminum Fin-copper Tube
Pipe Diameter mm Φ7
Rows-n Gap mm 2-1.4
Coil Length (LXDXW) mm 343X25.4X266.7
Fan Motor Speed rpm /
Output of Fan Motor W /
Fan Motor RLA A /
Fan Motor Capacitor μF /
To Next Page
