Gree GPC07AH-K3NNC3D

59
Maintenance
Service Manual
NO.
Description
Part Code
QtyGPC07AH-K3NNC4B GPC07AH-K3NNC4D
Product Code CK010018500 CK010021100
1 Membrane 63066055 63066055 1
2 Front Panel(up) 20006086 20006086 1
3 Display Board 30567018 30567025 1
4 Guide blade lever 10586017 10586017 1
5 Guide blade 1 10516064 10516064 5
6 Guide blade 2 10516063 10516063 1
7 Front Panel(down) 20006087S 20006087S 1
8 Right side plate 20056112 20056112 1
9 Discharge Tube 03616595 03616595 1
10 Inhalation Tube 03636603 03636603 1
11 Compressor and ttings 00106075 00106093 1
12 Overload Protector 00181093 00181150 1
13 Motor sub-assy(utter) 15006032 15006032 1
14 Splash Water Flywheel 10336003 10336003 1
15 Fan Motor 1501606202 1501606202 1
16 Castor 24236009 24236009 4
17 Chassis 22226062 22226062 1
18 Water level switch sub-assy 26156045 26156045 1
19 water level switch base 26156041 26156041 1
20 Water Level Switch 45010211 45010211 1
21 Water retaining box 20186259 20186259 1
22 Capillary Sub-Assy 03006524 03006524 1
23 Condenser Assy 01106132 01106132 1
24 Left side plate 20056111 20056111 1
25 Filter sub-assy2 11126071 11126071 1
26 Filter sub-assy1 11126070 11126070 1
27 Remote control box 20186094 20186094 1
28 Rear Plate 20056113 20056113 1
29 Evaporator Assy 01006100 01006107 1
30 Electric Box Assy 01406509 20106081 1
31 Ambient Temperature Sensor 390000451 390000451 1
32 Main Board 3013701001 30137038 1
33 Capacitor CBB65 33000081 33000081 1
34 Capacitor CBB61 33010010 3301074705 1
35 Electric Box Cover 01416013 01416013 1
36 Water Tray 12416009 12416009 1
37 Cover of Propeller Housing 22246086 22246086 1
38 Propeller Housing (upper) 22206044 22206044 1
39 Centrifugal fan 10316060 10316060 1
40 Propeller Housing(lower) 22206045 22206045 1
41 Guide blade lever 10586015 10586015 1
42 Air Louver 2 10516061 10516061 1
43 Air Louver 1 10516060 10516060 4
44 Fan Motor 15016069 1501606903 1
45 Motor Holder 26156089 26156089 1
46 Rear Grill 01476020 01476020 1
47 Centrifugal fan 1031606101 1031606101 1
48 Diversion Circle 10376038 10376038 1
49 Power Cord 4002046431 4002046431 1
50 Remote Controller 30510065 30510065 1
51 Rear Clip 2611601001 2611601001 1
52 Plastic Pipe End 06646017 06646017 1
53 PP hose 0523602203 0523602203 1
54 Joint 26116087 26116087 1
55 Drainage hose 05230013 05230013 1
Above data is subject to change without notice.
