60
Maintenance
Service Manual
NO.
Description
Part Code
QtyGPC08AH-K3NNC4B GPC08AH-K3NNC4A
Product Code CK010018800 CK01001431
1 Membrane 63066055 63066055 1
2 Front Panel(up) 20006086 20006086 1
3 Display Board 30567018 30567018 1
4 Guide blade lever 10586017 10586017 1
5 Guide blade 1 10516064 10516064 5
6 Guide blade 2 10516063 10516063 1
7 Front Panel(down) 20006087S 20006087S 1
8 Right side plate 20056112 20056112 1
9 Discharge Tube 03616594 03616141 1
10 Inhalation Tube 03636593 03636158 1
11 Compressor and ttings 00106079 00106069 1
12 Overload Protector 00181144 00180350 1
13 Motor sub-assy(utter) 15006032 15006006 1
14 Splash Water Flywheel 10336003 10336003 1
15 Fan Motor 1501606202 15016212 1
16 Castor 24236009 24236009 4
17 Chassis 22226062 22226062 1
18 Water level switch sub-assy 26156045 26156045 1
19 water level switch base 26156041 26156041 1
20 Water Level Switch 45010211 45010211 1
21 Water retaining box 20186259 20186093 1
22 Capillary Sub-Assy 03006525 03006513 1
23 Condenser Assy 01106100 01106106 1
24 Left side plate 20056111 20056111 1
25 Filter sub-assy2 11126071 11126071 1
26 Filter sub-assy1 11126070 11126070 1
27 Remote control box 20186094 20186094 1
28 Rear Plate 20056113 20056113 1
29 Evaporator Assy 01106131 01006065 1
30 Electric Box Assy 01406509 01406214 1
31 Ambient Temperature Sensor 390000451 390000451 1
32 Main Board 3013701001 3013701001 1
33 Capacitor CBB65 33000081 33000017 1
34 Capacitor CBB61 33010010 33010010 1
35 Electric Box Cover 01416013 01416013 1
36 Water Tray 12416009 12416009 1
37 Cover of Propeller Housing 22246086 22246086 1
38 Propeller Housing (upper) 22206044 22206044 1
39 Centrifugal fan 10316060 10316060 1
40 Propeller Housing(lower) 22206045 22206045 1
41 Guide blade lever 10586015 10586015 1
42 Air Louver 2 10516061 10516061 1
43 Air Louver 1 10516060 10516060 4
44 Fan Motor 15016069 15016044 1
45 Motor Holder 26156089 26156049 1
46 Rear Grill 01476020 01476020 1
47 Centrifugal fan 1031606101 10316061 1
48 Diversion Circle 10376038 10376038 1
49 Power Cord 4002046431 400220114 1
50 Remote Controller 30510065 30510065 1
51 Rear Clip 2611601001 2611601001 1
52 Plastic Pipe End 06646017 06646017 1
53 PP hose 0523602203 0523602203 1
54 Joint 26116087 26116087 1
55 Drainage hose 05230013 05230013 1
Above data is subject to change without notice.
