Maintenance
Service Manual
NO.
Description
Part Code
QtyGPC08AH-K3NNC5A
Product Code CK01001471 CK01001476
1 Front Panel Assy 20006109 20006123 1
2 Front Panel(up) 20006105 2000610501 1
3 Membrane 63066048 63066048 1
4 Display Board 30567017 30567017 1
5 Guide blade 1 10516064 1051606401 5
6 Guide blade 2 10516063 1051606301 1
7 Guide blade lever 10586017 1058601502 1
8 Decorative Board 20196026 2019602601S 1
9 Front Panel(down) 20006106 2000610601 1
10 Right side plate 20056112 2005611202 1
11 Discharge Tube 03616141 03616141 1
12 Inhalation Tube 03636158 03626162 1
13 Compressor and ttings 00106069 00106069 1
14 Overload Protector 00180350 00181069 1
15 Motor sub-assy(utter) 15006006 15006006 1
16 Splash Water Flywheel 10336003 10336003 1
17 Fan Motor 15016212 15016044 1
18 Castor 24236009 24236009 4
19 Chassis 22226062 22226062 1
20 Water level switch sub-assy 26156045 26156045 1
21 water level switch base 26156041 26156041 1
22 Water Level Switch 45010211 45010211 1
23 Water retaining box 20186093 20186531 1
24 Capillary Sub-Assy 03006513 03006513 1
25 Condenser Assy 01106106 01106106 1
26 Left side plate 20056111 2005611102 1
27 Filter sub-assy2 11126071 1112607102 1
28 Filter sub-assy1 11126070 11126070 1
29 Remote control box 20186094 2018609402 1
30 Rear Plate 20056113 2005611302 1
31 Evaporator Assy 01006065 01006065 1
32 Electric Box Assy 01406214 01406214 1
33 Ambient Temperature Sensor 390000451 390000451 1
34 Main Board 3013701001 3013701001 1
35 Capacitor CBB65 33000017 33000017 1
36 Capacitor CBB61 33010010 33010010 1
37 Electric Box Cover 01416013 01416013 1
38 Water Tray 12416009 12416009 1
39 Cover of Propeller Housing 22246086 20006123 1
40 Propeller Housing (upper) 22206044 22206044 1
41 Centrifugal fan 10316060 26156049 1
42 Propeller Housing(lower) 22206045 22206045 1
43 Guide blade lever 10586015 1058601701 1
44 Air Louver 2 10516061 1051606102 1
45 Air Louver 1 10516060 1051606002 4
46 Fan Motor 15016044 15016212 1
47 Motor Holder 26156049 26156049 1
48 Rear Grill 01476020 01476020 1
49 Centrifugal fan 10316061 10316061 1
50 Diversion Circle 10376038 10376038 1
51 Power Cord 400220114 400220114 1
52 Remote Controller 30510065 30510065 1
53 Rear Clip 2611601001 2611601002 1
54 Plastic Pipe End 06646017 0664601706 1
55 PP hose 0523602203 0523602203 1
56 Joint 26116087 2611608701 1
57 Drainage hose 05230013 05230013 1
Above data is subject to change without notice.
