64
Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
QtyGPC08AH-K3NNC5B
Product Code CK010018900 CK010018901
1 Front Panel Assy 20006123 2000610904 1
2 Front Panel(up) 2000610501 20006105 1
3 Membrane 63066048 6306603201 1
4 Display Board 30567017 30567017 1
5 Guide blade 1 1051606401 1051606402 5
6 Guide blade 2 1051606301 1051606302 1
7 Guide blade lever 1058601502 1058601501 1
8 Decorative Board 2019602601S 2019602602 1
9 Front Panel(down) 2000610601 20006106 1
10 Right side plate 2005611202 2005611201 1
11 Discharge Tube 03616594 03616594 1
12 Inhalation Tube 03636593 03636593 1
13 Compressor and ttings 00106079 00106079 1
14 Overload Protector 00181144 00181144 1
15 Motor sub-assy(utter) 15006032 15006032 1
16 Splash Water Flywheel 10336003 10336003 1
17 Fan Motor 1501606202 1501606202 1
18 Castor 24236009 24236009 4
19 Chassis 22226062 22226062 1
20 Water level switch sub-assy 26156045 26156045 1
21 water level switch base 26156041 26156041 1
22 Water Level Switch 45010211 45010211 1
23 Water retaining box 20186259 20186259 1
24 Capillary Sub-Assy 03006525 03006525 1
25 Condenser Assy 01106100 01106100 1
26 Left side plate 2005611102 2005611101 1
27 Filter sub-assy2 1112607102 1112607101 1
28 Filter sub-assy1 11126070 11126070 1
29 Remote control box 2018609402 2018609401 1
30 Rear Plate 2005611302 2005611301 1
31 Evaporator Assy 01106131 01106131 1
32 Electric Box Assy 01406509 01406509 1
33 Ambient Temperature Sensor 390000451 390000591 1
34 Main Board 3013701001 3013701001 1
35 Capacitor CBB65 33000081 33000081 1
36 Capacitor CBB61 33010010 33010010 1
37 Electric Box Cover 01416013 01416013 1
38 Water Tray 12416009 12416009 1
39 Cover of Propeller Housing 20006123 22246086 1
40 Propeller Housing (upper) 22206044 22206044 1
41 Centrifugal fan 26156049 10316060 1
42 Propeller Housing(lower) 22206045 22206045 1
43 Guide blade lever 1058601701 1058601702 1
44 Air Louver 2 1051606102 1051606101 1
45 Air Louver 1 1051606002 1051606001 4
46 Fan Motor 15016069 15016069 1
47 Motor Holder 26156089 26156089 1
48 Rear Grill 01476020 01476020 1
49 Centrifugal fan 1031606101 1031606101 1
50 Diversion Circle 10376038 10376038 1
51 Power Cord 4002046431 400220115 1
52 Remote Controller 30510065 30510065 1
53 Rear Clip 2611601002 2611601005 1
54 Plastic Pipe End 0664601706 0664601705 1
55 PP hose 0523602203 0523602207 1
56 Joint 2611608701 2611608704 1
57 Drainage hose 05230013 05230013 1
To Next Page
