66
Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
QtyGPC07AH-K3NNC5B
Product Code CK010018600 CK010018601
1 Front Panel Assy 20006109 20006133 1
2 Front Panel(up) 20006105 20006105 1
3 Membrane 63066048 63066048 1
4 Display Board 30567017 30567017 1
5 Guide blade 1 10516064 10516064 5
6 Guide blade 2 10516063 10516063 1
7 Guide blade lever 10586017 10586017 1
8 Decorative Board 20196026 20196026 1
9 Front Panel(down) 20006106 20006106 1
10 Right side plate 20056112 2005611202 1
11 Discharge Tube 03616595 03616595 1
12 Inhalation Tube 03636603 03636603 1
13 Compressor and ttings 00106075 00106075 1
14 Overload Protector 00181093 00181093 1
15 Motor sub-assy(utter) 15006032 15006032 1
16 Splash Water Flywheel 10336003 10336003 1
17 Fan Motor 1501606202 1501606202 1
18 Castor 24236009 24236009 4
19 Chassis 22226062 22226062 1
20 Water level switch sub-assy 26156045 26156045 1
21 water level switch base 26156041 26156041 1
22 Water Level Switch 45010211 45010211 1
23 Water retaining box 20186259 20186259 1
24 Capillary Sub-Assy 03006524 03006524 1
25 Condenser Assy 01106132 01106132 1
26 Left side plate 20056111 2005611102 1
27 Filter sub-assy2 11126071 1112607102 1
28 Filter sub-assy1 11126070 11126070 1
29 Remote control box 20186094 2018609402 1
30 Rear Plate 20056113 2005611302 1
31 Evaporator Assy 01006100 01006100 1
32 Electric Box Assy 01406509 01406509 1
33 Ambient Temperature Sensor 390000451 390000451 1
34 Main Board 3013701001 3013701001 1
35 Capacitor CBB65 33000081 33000081 1
36 Capacitor CBB61 33010010 33010010 1
37 Electric Box Cover 01416013 01416013 1
38 Water Tray 12416009 12416009 1
39 Cover of Propeller Housing 22246086 22246086 1
40 Propeller Housing (upper) 22206044 22206044 1
41 Centrifugal fan 10316060 10316060 1
42 Propeller Housing(lower) 22206045 22206045 1
43 Guide blade lever 10586015 10586015 1
44 Air Louver 2 10516061 10516061 1
45 Air Louver 1 10516060 10516060 4
46 Fan Motor 15016069 15016069 1
47 Motor Holder 26156089 26156089 1
48 Rear Grill 01476020 01476020 1
49 Centrifugal fan 1031606101 1031606101 1
50 Diversion Circle 10376038 10376038 1
51 Power Cord 4002046431 4002046431 1
52 Remote Controller 30510065 30510065 1
53 Rear Clip 2611601001 2611601002 1
54 Plastic Pipe End 06646017 0664601706 1
55 PP hose 0523602203 0523602203 1
56 Joint 26116087 2611608701 1
57 Drainage hose 05230013 05230013 1
