67
Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
QtyGPC07AH-K3NNC5D
Product Code CK010021300 CK010021301 CK010021302
1 Front Panel Assy 20006559 00000300019 00000300141 1
2 Front Panel(up) 20006105 2000610501 2000610502 1
3 Membrane 6306603201 6306603201 6306603201 1
4 Display Board 30567026 30567026 30567032 1
5 Guide blade 1 10516064 1051606401 10516064 5
6 Guide blade 2 10516063 1051606301 1051606301 1
7 Guide blade lever 10586017 1058601701 1058601502P 1
8 Decorative Board 20196026S 2019602601S 2019602601P 1
9 Front Panel(down) 20006106 2000610601 2000610602 1
10 Right side plate 20056112 2005611202 20056112 1
11 Discharge Tube 03616595 03616595 03001300044 1
12 Inhalation Tube 03636603 03636603 03636603 1
13 Compressor and ttings 00106093 00106093 00106093 1
14 Overload Protector 00181150 00181150 00181150 1
15 Motor sub-assy(utter) 15006032 15006032 15006032 1
16 Splash Water Flywheel 10336003 10336003 10336003 1
17 Fan Motor 1501606202 1501606202 1501606903 1
18 Castor 24236009 24236009 24236009 4
19 Chassis 22226062 22226062 22226062 1
20 Water level switch sub-assy 26156045 26156045 26156045 1
21 water level switch base 26156041 26156041 26156041 1
22 Water Level Switch 45010211 45010211 45010211 1
23 Water retaining box 20186259 20186259 20186259 1
24 Capillary Sub-Assy 03006524 03006524 03006524 1
25 Condenser Assy 01106132 01106132 01100200145 1
26 Left side plate 20056111 2005611102 20056111 1
27 Filter sub-assy2 11126071 1112607102 11126071 1
28 Filter sub-assy1 11126070 11126070 11126070 1
29 Remote control box 20186094 2018609402 20186094 1
30 Rear Plate 20056113 2005611302 20056113 1
31 Evaporator Assy 01006107 01006107 01006107 1
32 Electric Box Assy 20106081 20106081 10000201954 1
33 Ambient Temperature Sensor 390000451 390000451 390000451 1
34 Main Board 30137038 30137038 30137051 1
35 Capacitor CBB65 33000081 33000081 33000081 1
36 Capacitor CBB61 3301074705 3301074705 3301074705 1
37 Electric Box Cover 01416013 01416013 01416013 1
38 Water Tray 12416009 12416009 12416009 1
39 Cover of Propeller Housing 22246086 22246086 22246086 1
40 Propeller Housing (upper) 22206044 22206044 22206044 1
41 Centrifugal fan 10316060 10316060 10316060 1
42 Propeller Housing(lower) 22206045 22206045 22206045 1
43 Guide blade lever 10586015 1058601502 1058601701P 1
44 Air Louver 2 10516061 1051606102 1051606102 1
45 Air Louver 1 10516060 1051606002 1051606002 4
46 Fan Motor 1501606903 1501606903 1501606903 1
47 Motor Holder 26156089 26156089 26156089 1
48 Rear Grill 01476020 01476020 01476020 1
49 Centrifugal fan 1031606101 1031606101 10316060 1
50 Diversion Circle 10376038 10376038 10376038 1
51 Power Cord 4002046431 4002046431 4002046431 1
52 Remote Controller 30510065 30510065 30510065 1
53 Rear Clip 2611601001 2611601002 2611601001 1
54 Plastic Pipe End 06646017 0664601706 06646017 1
55 PP hose 0523602203 0523602203 0523602203 1
56 Joint 26116087 2611608701 26116087 1
57 Drainage hose 05230013 05230013 05230013 1
To Next Page
