GREE U-Match 5 SERIES UNIT SERVICE MANUAL
111
Removal of gas liquid separator
Note: Before removing the gas liquid separator, make sure there is no refrigerant in the pipeline and power is cut off.
5. Secure the electric box and
arrange the wires as
required.
●Put the electric box back in place
and tighten up the screws.
●Arrange the wires as original.
6.Check and open the upper
and side panels.
●Check whether each component
and connection wire is well
connected.
●If everything is OK, install the
upper, left and right panels.
Tighten up the screws.
Removal of electronic expansion valve
Note: Before removing the electronic expansion valve, make sure there is no refrigerant in the pipeline and power is cut off.
1. Loosen the wire clamp
at the bottom of the
electric box and the
screws of electric box.
●Remove the upper, lower and
front panels.
●Loosen the wire clamp at the
bottom of the electric box.
●Unscrew the screws of electric
box.
To Next Page
