Gree GUD35PS/A-T Service Manual

GREE U-Match 5 SERIES UNIT SERVICE MANUAL
180
Appendices
1 Resistance/temperature lists of temperature sensors
1.1 Voltage list of 15 kΩ temperature sensors (including ODU and
IDU temperature sensors)
Temperature
(°C)
Resistance
(kΩ)
Voltage (V)
Temperature
(°C)
Resistance
(kΩ)
Voltage (V)
-20
144
0.311
71
2.523
2.825
-19
138.1
0.323
72
2.439
2.838
-18
128.6
0.345
73
2.358
2.852
-17
121.6
0.362
74
2.28
2.865
-16
115
0.381
75
2.205
2.877
-15
108.7
0.4
76
2.133
2.889
-14
102.9
0.42
77
2.064
2.901
-13
97.4
0.44
78
1.997
2.912
-12
92.22
0.462
79
1.933
2.923
-11
87.35
0.484
80
1.871
2.934
-10
82.75
0.506
81
1.811
2.945
-9
78.43
0.53
82
1.754
2.955
-8
74.35
0.554
83
1.699
2.964
-7
70.5
0.579
84
1.645
2.974
-6
66.88
0.605
85
1.594
2.983
-5
63.46
0.631
86
1.544
2.992
-4
60.23
0.658
87
1.497
3.001
-3
57.18
0.686
88
1.451
3.009
-2
54.31
0.714
89
1.408
3.017
-1
51.59
0.743
90
1.363
3.025
0
49.02
0.773
91
1.322
3.033
1
46.8
0.801
92
1.282
3.04
2
44.31
0.835
93
1.244
3.047
3
42.14
0.866
94
1.207
3.054
4
40.09
0.899
95
1.171
3.061
5
38.15
0.931
96
1.136
3.068
6
36.32
0.965
97
1.103
3.074
7
34.58
0.998
98
1.071
3.08
8
32.94
1.033
99
1.039
3.086
9
31.38
1.067
100
1.009
3.092
10
29.9
1.102
101
0.98
3.098
11
28.51
1.138
102
0.952
3.103
