Gree GUD35PS/A-T Service Manual

GREE U-Match 5 SERIES UNIT SERVICE MANUAL
179
No.
Material name
Finished Product Code
Remarks
1
Remote Controller
305001060024
1
2
Ambient Temperature Sensor
3900012123
1
3
Tube Sensor
3900020720G
1
4
Right Cover Plate
26909400071
1
5
Right Side Plate
26909400074
1
6
Installation Supporting Frame(right)
01809402
1
7
Axial Bush
10542704
2
8
Evaporator Assay
011001060183
1
9
Rotating Shaft 3
26909430
6
10
Guide Louver
200004500426
2
11
Crankshaft
200023000001
2
12
Stepping Motor
1521240206
2
13
Display Board
30294000009
1
14
Base Plate Assay
011007060032
1
15
Clapboard Sub-Assay
01249400019
1
16
Left Cover Plate
26909400070
1
17
Installation Supporting Frame(Left)
01809401
1
18
Main Board
300002060226
1
19
Terminal Board
42018000551
1
20
Terminal Board
42000100000202
1
21
Electric Box Assay
100002003030
1
22
Support Of Motor Bearing
01792408
2
23
O-Gasket of Bearing
76512404
1
24
Propeller Housing(Lower)
200230000001
4
25
Roller Wheel
700004000001
2
26
Joint Slack
73018731
2
27
Brushless DC Motor
15709400005
1
28
Centrifugal Fan
103003000001
4
29
Propeller Housing(Upper)
200230000002
4
30
Rear Side Plate Sub-Assay
017051000006
1
31
Filter Sub-Assay
111001000001
3
32
Drainage Pipe Sub-Assay
05235434
1
33
Swing Lever
10582009
4
34
Air Louver
200007000001
20
35
Supporter(Guide Louver)
26909400076
3
36
Water Tray
200063000002
1
37
Top Cover
01269400013P
1
38
Front Grill Sub-assay
26909400066
4
