Gree GUD35PS/A-T Service Manual

GREE U-Match 5 SERIES UNIT SERVICE MANUAL
173
No.
Material name
Finished Product Code
Quantity
6
Swing Lever
10582009
2
7
Air Louver
200007000001
10
8
Supporter(Guide Louver)
26909400076
1
9
Right Cover Plate
26909400071
1
10
Installation Supporting Frame(Right)
01809402
1
11
Right Side Plate
26909400074
1
12
Axial Bush
10542704
2
13
Front Panel
200003000001
1
14
Guide Louver
200004000046
2
15
Evaporator Assay
011001000487
1
16
Rotating Shaft 3
26909430
2
17
Display Board
30294000009
1
18
Base Plate Assay
011007000032
1
19
Crankshaft
200023000001
2
20
Stepping Motor
1521240215
2
21
Electric Box Assay
100002003030
1
22
Main Board
300002060226
1
23
Terminal Board
42018000551
1
24
Terminal Board
42000100000202
1
25
Installation Supporting Frame(Left)
01809401
1
26
Left Cover Plate
26909400070
1
27
Clapboard Sub-assay
017021000088
1
28
Propeller Housing(Lower)
200230000001
2
29
Rear Side Plate Sub-assay
017051000046
1
30
Brushless DC Motor
15706000037
1
31
Centrifugal Fan
103003000001
2
32
Propeller Housing(Upper)
200230000002
2
33
Filter Sub-assay
111001000001
1
34
Top Cover
012148000046
1
35
Front Grill
200226000004
2
