Gree GUD35PS/A-T Service Manual

GREE U-Match 5 SERIES UNIT SERVICE MANUAL
176
No.
Material name
Finished Product Code
Quantity
1
Remote Controller
305001060024
1
2
Temperature Sensor
390001921
1
3
Ambient Temperature Sensor
3900012123
1
4
Drainage Pipe Sub-Assay
05235434
1
5
Water Tray
200063000003
1
6
Swing Lever
10582009
3
7
Air Louver
200007000001
15
8
Supporter
26909400076
2
9
Rotating Shaft 3
26909430
4
10
Right Cover Plate
26909400071
1
11
Installation Supporting Frame(Right)
01809402
1
12
Right Side Plate
26909400074
1
13
Axial Bush
10542704
2
14
Guide Louver
200004500422
2
15
Evaporator Assay
011001000136
1
16
Display Board
30294000009
1
17
Crankshaft
200023000001
2
18
Stepping Motor
1521240206
2
19
Base Plate Assay
011007000038
1
20
Electric Box Assay
100002003030
1
21
Installation Supporting Frame(Left)
01809401
1
22
Main Board
300002060226
1
23
Terminal Board
42018000551
1
24
Terminal Board
42000100000202
1
25
Left Cover Plate
26909400070
1
26
Support Of Motor Bearing
01792408
1
27
O-Gasket of Bearing
76512404
1
28
Clapboard Assay
000075000040
1
29
Propeller Housing(Lower)
200230000001
3
30
Rotary Axis
700004500433
1
31
Filter Sub-Assay(Rear Side Plate)
111001000001
2
32
Rear Side Plate Sub-Assay
017051000005
1
33
Joint Slack
73018731
1
34
Fan Motor
1570520000501
1
35
Centrifugal Fan
103003000001
3
36
Propeller Housing(Upper)
200230000002
3
37
Front Grill Sub-Assay
26909400066
3
38
Top Cover
01269400012
1
