GREE U-Match 5 SERIES UNIT SERVICE MANUAL
16
(2) P4 (LCD displays 04)
(3) P5 (LCD displays 05)
(4) P6 (LCD displays 06)
(5) P7 (LCD displays 07)
Note: You can select P03, P04, P05, P06, P07 in fan mode of indoor fan motor, which means different fan mode combinations
are corresponding to different static pressure. Ex-factory defaulted mode is P05. You can set the mode through wired controller. S01,
S02, S03„„S12, S13 means the rotation speed of indoor unit is from low to high.
Combination relationship of P03, P04, P05, P06, P07
Static
pressure
selection
b.There are 9 selections for high static pressure duct:
(1) P1 (LCD displays 01)
(2) P2 (LCD displays 02)
(3) P3 (LCD displays 03)
(4) P4 (LCD displays 04)
(5) P5 (LCD displays 05)
(6) P6 (LCD displays 06)
(7) P7 (LCD displays 07)
(8) P8 (LCD displays 08)
(9) P9 (LCD displays 09)
Note: You can select P01, P02, P03, P04, P05, P06, P07, P08, P09 in fan mode of indoor fan motor, which means different fan
mode combinations are corresponding to different static pressure. Ex-factory defaulted mode is P05. You can set the mode through
wired controller. S01, S02, S03„„S12, S13 means the rotation speed of indoor unit is from low to high.
Combination relationship of P01, P02, P03, P04, P05, P06, P07, P08, P09
Static
pressure
selection
2.3.9.10 Selecting compensation of temperature sensor at air return
Under debugging state, press Mode button to adjust to “12” in temperature displaying zone. Timer zone displays setting
state and press ▲ or ▼ button to adjust. There are 16 selections:
