Service Manual
84
Installation and Maintenance
Procedure
Steps
3.Remove grille
4.Remove front side plate
5.Remove right side plate
Remove screws used for xing the
grille and the rear side plate, the grille
and the chassis, and then remove the
grille.
Remove screws used for xing the front side
plate, lift the front side plate upwards and
then remove it.
Remove screws used for xing the right side
plate, and then remove the right side plate.
Grille
Screw Screw
Front side plate
Right side plate
