Service Manual
86
Installation and Maintenance
Valve
Compressor
Gas-liquid separator
9.Remove 4-way valve
10.Remove valve
Twist off the nuts used for xing the 4-way
valve wire, and then take out the coil. Use wet
guaze to wrap the 4-way valve, unsolder the
spot weld connected to the 4-way valve and
then remove the 4-way valve. The welding
process must be as quick as possible, and
then gauze should be kept wet all the time.
Please note that don’t let the ame burn the
leading wired of compressor.
Remove screws used for xing the valve,
unsolder the pipeline connected with the valve
and then remove the valve.
11.Remove compressor sub-assy
Unsolder the pipeline connected with the
compressor, remove 3 foot nuts on the
compressor, and then the compressor and the
gas-liquid separator can be removed.
4-way valve
Procedure
Steps
