Gree GWC User Manual

86
Installation and Maintenance
Service Manual
Some models may not contain some parts, please refer to the actual product.
NO. Description
1 Front Panel
2 Guide Louver
3 Axile Bush
4 Front Case
5 Screw Cover
6 Filter Sub-Assy
7 Air Louver (left)
8 Helicoid Tongue
9 Left Axile Bush
10 Rear Case Sub-Assy
11 Cross Flow Fan
12 Ring of Bearing
13 O-Gasket sub-assy of Bearing
14 Evaporator Assy
15 Evaporator Support
16 Wall Mounting Frame
17 Fan Motor
18 Motor Press Plate
NO. Description
19 Connecting pipe Clamp
20 Drainage Hose
21 Crank
22 Stepping Motor
23 Air Louver(right)
24 Electric Box Assy
25 Main Board
26 Supporter(Electric Box)
27 Terminal Board
28 Cable Clamp
29 Electric Box Cover
30 Display Board
31 Power Cord
32 Connecting Cable
33 Connecting Cable
34 Remote Controller
35 Rear Grill Sub-assy 2
36 Rear Grill Sub-assy 1

Gree GWC Specifications

General

Power Supply	220-240V, 50Hz
Type	Split
Refrigerant	R410A
Features	Auto Restart, Sleep Mode, Turbo Mode
EER (Energy Efficiency Ratio)	3.5
Noise Level	50 dB (Outdoor)
Cooling Capacity	12000 BTU/h
Heating Capacity	12000 BTU/h
Weight	Indoor: 9 kg, Outdoor: 30 kg
