Gree GWC User Manual

88
Installation and Maintenance
Service Manual
Some models may not contain some parts, please refer to the actual product.
NO. Description
1 Front Panel
2 Filter Sub-Assy
3 Screw Cover
4 Electric Box Cover
5 Rear Grill Sub-assy
6 Front Case
7 Cable Clamp 2
8 Terminal Board
9 Supporter
10 Jumper
11 Main Board
12 Electric Box
13 Display Board
14 Air Louver
15 Helicoid Tongue
16 Crank
17 Stepping Motor
NO. Description
18 Rear Case
19 Cable Cross Plate
20 Connecting pipe clamp
21 Fan Motor
22 Motor Press Plate
23 Cross Flow Fan
24 Wall Mounting Frame
25 Heat Insulating Hose
26 Evaporator Assy
27 Evaporator Support
28 Remote Controller
29 Temperature Sensor
30 Connecting Cable
31 Connecting Cable
32 O-Gasket sub-assy of Bearing
33 Ring of Bearing
34 Guide Louver
