9
Technical Information
Service Manual
Model GWC18ATDXD-D3DNA1A GWH18ATDXD-D3DNA1A
Product Code CB574003300 CB574003200
Power
Supply
Rated Voltage V~ 208/230 208/230
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity Btu/h 17400 17600
Heating Capacity Btu/h / 19100
Cooling Power Input W 1729 1750
Heating Power Input W / 1750
Cooling Current A 7.95 7.95
Heating Current A / 7.95
Rated Input W 2200 2300
Rated Current A 9.5 9.5
EER (Btu/h)/W 10.05 10.05
COP (Btu/h)/W / 10.90
SEER 19(SEER) 19
(
SEER2) 17.5(SEER) 17.5
(
SEER2)
HSPF / 9(HSPF) 8.5(HSPF2)
Air Flow Volume CFM 618/512/471/436/395/336/283 618/512/471/436/395/336/283
Dehumidifying Volume Pint/d 3.8 3.8
Application Area yd
2
28-41 28-41
Indoor Unit
Indoor Unit Model GWC18ATDXD-D3DNA1A/I GWH18ATDXD-D3DNA1A/I
Product Code of Indoor Unit CB574N03300 CB574N03200
Fan Type Cross-ow Cross-ow
Fan Diameter Length(DXL) mm Ф106X706 Ф106X706
Cooling Speed r/min 1350/1200/1120/1050/980/860/750 1350/1200/1120/1050/980/860/750
Heating Speed r/min / 1350/1200/1120/1050/950/850/750
Fan Motor Power Output W 45 45
Fan Motor RLA A 0.7 0.7
Fan Motor Capacitor μF / /
Heater Power Input W / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Ф5 Ф5
Evaporator Row-n Gap mm 2-1.2 2-1.2
Evaporator Coil Length (LXDXW) mm 700X22.8X381 700X22.8X381
Swing Motor Model MP35CJ MP35CJ
Swing Motor Power Output W 2.5 2.5
Fuse Current A 3.15 3.15
Sound Pressure Level dB (A) 50/46/44/42/40/36/32
Cooling:50/46/44/42/40/36/32
Heating:49/46/4441/38/34/30
Sound Power Level dB (A) 60/56/55/52/50/46/42
Cooling:60/56/54/52/50/46/42
Heating:59/56/54/51/48/44/40
Dimension (WXHXD) inch 37 1/8X13 7/64X9 11/16 37 1/8X13 7/64X9 11/16
Package Carton Dimension
(LXWXH)
inch 39 7/32X15 5/8X12 9/32 39 7/32X15 5/8X12 9/32
Package Dimension (LXWXH) inch 39 13/32X15 15/16X12 43/64 39 13/32X15 15/16X12 43/64
Net Weight Ib 28.7 28.7
Gross Weight Ib 34.2 34.2
To Next Page
