Technical Information
Service Manual
Model GWC09ATCXB-A3DNA1A
GWH09ATCXB-A3DNA1A
GWH09ATCXB-A3DNA3A
Product Code CB574001700
CB574001600
CB590000300
Power
Supply
Rated Voltage V~ 115 115
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity Btu/h 9100 9100
Heating Capacity Btu/h / 10000
Cooling Power Input W 771 771
Heating Power Input W / 814
Cooling Current A 8.7 8.7
Heating Current A / 9.2
Rated Input W 1350 1450
Rated Current A 17.5 17.5
EER (Btu/h)/W 11.3 11.3
COP (Btu/h)/W / 12.3
SEER 19.5(SEER)19.5(SEER2) 19.5(SEER)19.5(SEER2)
HSPF / 9.8(HSPF)8.6(HSPF2)
Air Flow Volume CFM 353/282/264/229/211/194/158 353/282/264/229/211/194/158
Dehumidifying Volume Pint/d 1.69 1.69
Application Area yd
2
14-22 14-22
Indoor Unit
Indoor Unit Model GWC09ATCXB-A3DNA1A/I
GWH09ATCXB-A3DNA1A/I
GWH09ATCXB-A3DNA3A/I
Product Code of Indoor Unit CB574N01700
CB574N01600
CB590N00300
Fan Type Cross-ow Cross-ow
Fan Diameter Length(DXL) mm Ф94X630 Ф94X630
Cooling Speed r/min 1350/1150/1100/1000/950/850/750 1350/1150/1100/1000/950/850/750
Heating Speed r/min / 1300/1100/1050/1000/950/850/800
Fan Motor Power Output W 20 20
Fan Motor RLA A 0.40 0.40
Fan Motor Capacitor μF 4 4
Heater Power Input W / 68
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Ф5 Ф5
Evaporator Row-n Gap mm 2-1.3 2-1.3
Evaporator Coil Length (LXDXW) mm 634X22.8X266.7 634X22.8X266.7
Swing Motor Model MP24HF MP24HF
Swing Motor Power Output W 1.5 1.5
Fuse Current A 3.15 3.15
Sound Pressure Level dB (A) 41/37/35/33/31/28/26
Cooling:41/37/35/33/31/28/26
Heating:41/36/35/34/31/29/27
Sound Power Level dB (A) 51/47/45/43/41/38/36
Cooling:51/47/45/43/41/38/36
Heating:51/46/45/44/41/39/37
Dimension (WXHXD) inch 32 7/8X10 53/64X7 7/8 32 7/8X10 53/64X7 7/8
Package Carton Dimension
(LXWXH)
inch 35 1/32X12 61/64X10 15/64 35 1/32X12 61/64X10 15/64
Package Dimension (LXWXH) inch 35 15/64X13 37/64X10 43/64 35 15/64X13 37/64X10 43/64
Net Weight Ib 19.8 19.8
Gross Weight Ib 24.25 24.25
